For all quality laser scanning and inspection, Chasestead are accredited to AS9100D & BS EN ISO 9001.2015 and supply full dimensional reports with all components in line with this specification or to meet your specific requirements using our CNC Co-ordinate Measuring Machines (CMM).

VIEW OUR CERTIFICATION HERE

Faster 3D scanning

The MetraSCAN 3D features 15 laser crosses and a high measurement rate to accelerate 3D scanning processes. Thanks to quick setup and onboarding, real-time scans and ready-to-use files, your 3D scanning workflow will never have been faster.

CMM inspection has certain limitations including surfaces and tubes, laser scanning is ideal as it measures the entire surface rather than only measure specific points, it also extremely good for measuring tubular fabrications.

The data generated is also very intuitive, producing a weather map that can be super-imposed onto CAD dater that shows the difference between CAD nominal and the finished surface.

Our CNC Co-ordinate Measuring Machines [CMM] have a measuring ability of 2000mm x 1300mm x 1000mm.

PC-DMIS is an advanced measurement and analysis programme for use with co-ordinate measuring machines. This has increased our programming capability and allows us to analyse the results using SPC Lighthouse software.

PC-DMIS provides a bi-directional link with our CAD systems enabling inspection to receive your CAD data and inspect directly from it.

For jig tooling, reverse engineering or ‘off site’ / ‘in situ’ inspection we are able to offer use of our portable CMM Inspection Arm.

High measurement rate – 1,800,000 measurements/second

Large scanning area for all types of parts – 15 laser crosses

  • High resolution 15 laser head scanning equipment
  • Any size object can be scanned from small engineered parts to buildings
  •  Data generated by scanning is an STL File
  • External surface of a car can be completed in a matter of hours
  • Rapid inspection of complex assemblies
  • Easy to read “weather map” inspection reports

All products have full material traceability with Certificates of Conformity.

In addition to this we are also approved suppliers to the following companies:


Eaton Aerospace
Fowlers Aerospace
Rolls Royce
Siemens
MOD
BAE
Meggitt Aerospace
Contour Seating
Aeromet
Aeroflexx
Selex
MBDA
